- Rated Current (Ie)
- 16A, 20A, 25A, 32A, 40A, 50A, 63A, 80A, 100A
- Insulation Voltage (Ui)
- AC 690V
- Rated Voltage (Ue)
- 220VAC (2P), 400VAC (3P, 4P)
- Grade
- Grade PC: Able to make and withstand, not to break short-circuit current
- Use Category
- AC-33iB
- Poles
- 2P, 3P, 4P
- Weight (kg)
- 0.62 (2P), 0.72 (3P), 0.81 (4P)
- Electrical Life
- 2000 times
- Mechanical Life
- 5000 times
- Rated Conditional Short-Circuit Current (Iq)
- 50kA
- SCPD (Fuse)
- RT16-00-63A
- Rated Impulse Withstand Voltage
- 8kV
- Control Circuit
- Rated control voltage: AC 220V, 50Hz; Correct working condition: 85%-110% of Us
- Auxiliary Circuit
- AC 220V / AC 110V, 50/60Hz
- Contact Transfer Time
- <50ms
- Operating Transfer Time
- <50ms
- Return Transfer Time
- <50ms
- Off-Time
- <50ms
- Temperature Range
- -5°C to +40°C; average temperature not exceeding 35°C in 24 hours
